Explosion-proof Button Controller - TCM-ZA50-1x

The TCM-ZA50-1X is a high-performance Explosion-proof Button Controller designed specifically for hazardous industrial environments. It serves as a reliable interface for controlling equipment where safety in the presence of explosive gases or combustible dust is a critical requirement.

Description
The TCM-ZA50-1X is a rugged, explosion-proof control unit enclosed in a high-grade glass-reinforced polyester (GRP) housing. Known for its elegant design, this controller is not only corrosion and impact-resistant but also excels in static electricity resistance. It is an essential component for safety-critical sites such as chemical plants, refineries, and offshore platforms.

Key Features
Advanced Material Engineering: The GRP enclosure offers superior protection against corrosion, impacts, and thermal stress while remaining lightweight.
Explosion-Proof Certified: Designed for Zone 1 and Zone 2 (explosive gas) and Zone 20, 21, and 22 (combustible dust), complying with international standards like IEC/EN 60079.
Intelligent Sealing: Features a Labyrinth sealing structure that provides excellent waterproof and dustproof capabilities (IP66).
Vandal & Corrosion Resistant: Equipped with stainless steel fasteners and anti-drop design, ensuring durability and easy maintenance in the field.
Reliable Switching: Built-in high-capacity explosion-proof control switch that provides high reliability, long operational life, and a compact footprint.
Safety Protected: Includes an optional button cover protection to prevent accidental activation.

Technical Specifications
Explosion-Proof Mark: ATEX Ex de IIC T6 Gb, Ex tD A21 IP66
Rated Voltage: 12V – 380V AC/DC
Contact/Current: 1NO + 1NC / 10A
Operating Temperature: Compatible with T1–T6 temperature classes
Inlet Thread: G3/4" - G1/2"
Cable Outer Diameter: 9mm – 14mm
Protection Grade: IP66
Material: Glass Reinforced Polyester (GRP)

Industrial Applications
This controller is built for the most demanding hazardous environments:
Petroleum & Refining: Essential for control systems in oil extraction, refinery units, and fuel storage areas.
Chemical & Pharmaceutical: Ideal for sites handling volatile chemical substances where spark prevention is mandatory.
Military & Defense: Used in facilities requiring high-grade explosion-proof infrastructure.
Textile & Printing: Suitable for areas where combustible dust or solvent vapors are common.
Offshore & Marine: The corrosion-resistant GRP material makes it perfect for humid, salt-heavy environments like offshore oil rigs and galangan kapal (shipyards).
