Single Zone Desktop IP Call Station - TCM-PM9801RM
Short Description
The TCM-PM9801RM is a highly intelligent Single Zone Desktop IP Call Station. Despite its compact form factor, this device fully supports SIP and multicast technology, allowing it to make voice calls to various IP terminals (such as IP Speakers or IP Intercoms) very quickly—with a reboot time of less than 1 second!
Key Features
Standalone Paging: Does not always require a server; can perform paging directly to target devices via the network.
One-Touch Dialing: Features programmable buttons that can be configured for quick calls to specific zones or groups.
Clear Sound Quality: Equipped with an Acoustic Echo Canceller (AEC) so that announcements remain clear and free of buzzing.
Ergonomic Design: Uses a gooseneck mic with an LED indicator, making it very comfortable for long-duration use.
Cloud Ready: Supports cloud integration for remote configuration flexibility.
Technical Specifications
Network: 10/100M LAN with RJ45 connector.
Protocols: TCP/IP, SIP, Multicast, ICMP, UDP, DNS, IGMP.
Power Supply: DC12V.
Material: Durable ABS Plastic.
Dimensions: 150 x 140 x 55 mm.
Weight: 0.8 Kg.
Accessories: Includes a windproof sponge (mic protection foam).
Industrial Applications
This device is highly suitable for use in:
Security Center: For emergency announcements or security instructions to the entire building area.
Hospitals: As a paging communication tool from nurses/receptionists to waiting rooms.
Industrial & Parking Areas: To provide real-time directions or information for employees/visitors.
Schools/Campuses: Used in administrative offices or principal's offices to provide announcements to classrooms (per zone).
